GROHE SPA

Atrio Icon 3D 3-hole wall-mount basin mixer

Toote number
20614SD0
EAN-kood
4005176556920
Värvus
stainless steel
30 226,48
Soovitatav jaehind koos käibemaksuga
Küsige kohe

The GROHE Atrio Icon 3D basin mixer in pure stainless steel – cutting-edge technology meets exceptional craftsmanship

If you are searching for a premium tap then this three-hole wall-mounted basin mixer strikes just the right note of luxury: The slim silhouette of the elegant spout is perfectly complemented by two chic handles in a coordinated design, making a stylish set that also offers high functionality, solid reliability and ultimate sustainability. The spout, with a comfortable 235mm projection, provides a pure, laminar water flow. Operation is via the two handles – with subtle red and blue markings for hot and cold water – offering precise volume and temperature control thanks to the state-of-the-art ceramic headparts inside. The resource-efficient 3D printing technology is extremely sustainable as the metal raw material is added and formed layer by layer, rather than subtracted or cut out of a solid figure. Finally, the product is hand-finished by a grinding and polishing artist to guarantee the highest quality standards. GROHE Atrio Icon 3D – creating the impossible.

Põhijooned

  • open spout for pure laminar water flow
  • red and blue markings on handles for hot and cold water
  • valves hot/cold with ceramic headparts
  • pressure-proof, flexible connection hoses between spout and side valves
  • projection 235 mm
  • technical data
  • flow pressure min 0.5 bar
  • recommended pressure 1.0 - 5.0 bar
  • if static pressure is more than 5 bar fit pressure reducer
  • avoid major pressure differences between cold and hot water supply
  • flow rate at 3 bar flow pressure: approx. 5 l/min
  • max. temperature hot water inlet: 80°C
  • recommended temperature hot water inlet (energy saving): 60°C
Järjekorranumber Toote kirjeldus Tellimuse number
* Lisatarvikud
1 Ceramic headpart, 1/2" 45882000
1.1 O-ring Ø 18.2 x Ø 1.7 0392400M
2 Ceramic headpart, 1/2" 45883000
2.1 O-ring Ø 18.2 x Ø 1.7 0392400M
3 Flexible connection hose 45704000
4 Coupling nut 1/2" 1290100M
4.1 Fibre seal Ø 18,5 x Ø 12 x 2 0138900M
5 Waste set with push-open plug 65807000
6 Fixing clamp 6554100M
7 Coupling nut 1/2" x 14.5 mm 1290200M*
